4K UHD Simultaneously split to two different HDMI displays from the one HDMI source, such as a Blu-ray player, set-top box, games console, or media player.
With 4K x 2K Ultra High Definition (UHD) support, there's no reduction in picture quality.
Supports audio up to 7.1 surround sound, HDCP 2.2 for the latest hardware compatibility, and 10-bit HDR (High Dynamic Range) for a wider range of lifelike colours and brightness.
The smart EDID (Extended Display Identification Data) support ensures your monitor knows how to configure correctly to match the source signal.
Features: Up to 4K x 2K Video Resolution High-Dynamic-Range (HDR) Video Support HDCP, 3D & CEC Bypass Features: . Up to 4K x 2K Video Resolution . High-Dynamic-Range (HDR) Video . EDID Data Transmission . HDCP, 3D & CEC Bypass
Specifications: Inputs: 1 x HDMI Outputs: 2 x HDMI HDMI: 2.0b HDCP: 2.2, 1.4 HDR: 10 Resolution: Up to 4K (3840 x 2160) @ 60/50/30Hz Video Bandwidth: 18Gbps Audio Support: LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X Power Supply: 5V, 1A Colour Depth: 10-bit Dimensions: 100(W) x 56(D) x 16(H)mm
Product Specifications
- Digital Audio Format : LPCM, Dolby Digital/Plus/Ex, DTS-HD Master Audio 5.1, Dolby TrueHD, DTS-HD, Dolby Atmos, DTS-X
- Width : 100.0mm
- Height : 16.0mm
- Depth : 56.0mm
- PSU Powers : Main Product
- DC Plugpack Voltage : 5.0V
- DC Current Draw : 200.0mA
- Suitable PSU Included : true
- Supported Display Resolution : 4K UHD (3840 x 2160)
- Resolution Frequency : 30.0Hz, 60.0Hz
- HDMI Version : 2.0b
- HDMI Maximum Data Rate : 18.0Gb/s
- HDCP Version : 2.2, 1.4
- HDR Version : HDR 10
- Switcher/Converter Type : Distribution Amplifier Splitter
- Input type : HDMI
- Input Connection : HDMI Type-A
- Number of inputs : 1.0pc
- Output Type : HDMI
- Output Connection : HDMI Type-A
- Number of Outputs : 2.0pc
| Length : 20 cm |
Width : 11.5 cm |
| Height : 6.5 cm |
